IEC 62560 Test Equipment,Testing And Measuring Equipment/Allowed Subcontracting IEC 62560 Edition 1 2011 – A1:2015

Name: IEC 62560 Test EquipmentTesting And Measuring EquipmentAllowed Subcontracting IEC 62560 Edition 1 2011 A12015
Brand: kingpo
Price: 1 USD

Buy cheap IEC 62560 Test Equipment,Testing And Measuring Equipment/Allowed Subcontracting IEC 62560 Edition 1 2011 – A1:2015 product

Brand Name : kingpo

Model Number : KP6560

Certification : iso9001

Place of Origin : china dongguan

MOQ : 1

Price : To be quoted

Supply Ability : 1000 pcs per month

Packaging Details : safety carton pack or plywood box

MATEL : 420

standant : IEC62560

MODEL : IEC60601-3 GAUGE

Delivery Time : 7 working days

Payment Terms : T/T

Contact Now

IEC 62560 Test Equipment,Testing And Measuring Equipment/Allowed Subcontracting IEC 62560 Edition 1 2011 – A1:2015

TESTING AND MEASURING EQUIPMENT/ALLOWED SUBCONTRACTING

IEC 62560 Edition 1 2011 – A1:2015

Self-ballasted LED lamps for general lighting services by voltage > 50 V - Safety specifications

“R” Required

“S” May be subcontracted, see OD 2012

“SF” Specialized Facility, see IECEE 02-2

“W” Witness testing in the categories “MED” and “MEAS”

“3PPS” Three Phase Power Supply required

Clause	Measurement/testing	Testing / measuring equipment / material needed	Price (RMB)	Subcontracting
5.3	Marking	Hexane,		R
		water,
		piece of cloth
6.1	Cap interchangeability - Table 1	Gauges according to IEC 60061-1 and IEC 60061-3		R
6.2	Bending moment and mass imparted by the lamp at the lamp holder	Test finger with indicating device and with force meter,		R
6.2		Weighting device		R
7	Protection against accidental contact with live parts	Standard Test finger (IEC 60529) ,		R
		IEC 60061-3, sheet 7006-51A for E27 caps
		IEC 60061-3, sheet 7006-55 for E14 caps
		Mega ohmmeter,
		High Voltage transformer
8.2 - 8.3	Insulation resistance and electric strength after humidity treatment	Humidity cabinet,		R
		Mega ohmmeter,	Use same as Clause 7
		High Voltage transformer	Use same as Clause 7
9.2.1	Torsion resistance of unused lamps	Holder for torque test Figure 3 and figure 4		R
9.4	Axial strength of Edison Caps	Gauges according table 4,		R
9.4	Axial strength of Edison Caps	dynamometer		R
10	Cap temperature rise	Temperature test cap		R
10	Cap temperature rise	Temperature test draught-proof enclosure		R
11	Resistance to heat	Heating cabinet,		R
11	Resistance to heat	Ball pressure test apparatus		R
12	Resistance to flame and ignition	Needle flame test apparatus,		R
12	Resistance to flame and ignition	Glow-wire test apparatus		R
14	Creepage distances and clearances	Digital calliper (or equivalent)		R
15	Abnormal operation	Circuit shown in Figure 8 (for non-dimmable lamps on a dimmer or an electronic switch),		R
15	Abnormal operation	test finger		R
17	Photobiological safety	UV radiation test instruments / retinal blue light hazard test instruments (Equipment List of IEC/TR 62778:2012, Edition 1.0),		S
17	Photobiological safety	Goniophotometric measurement system		S
18	Ingress protection	IP X4 test equipment		R
